Monolithic Power Systems (MPS) MP2980 36V Buck-Boost Controllers

Monolithic Power Systems (MPS) MP2980 36V Buck-Boost Controllers are designed to regulate different output voltages with a wide input voltage (V_IN) range and high efficiency. The MP2980 features a digital interface that supports output voltage (V_OUT) configuration, V_OUT slew rate control, and constant output current (I_OUT) limit configuration. These features make the MP2980 ideal for USB power delivery (PD) designs in USB Type-C™ power supplies.

The MPS MP2980 implements valley current control in buck mode and peak current control in boost mode to deliver fast load transient response and smooth buck-boost mode transients. The MP2980 offers forced continuous conduction mode (FCCM) and a configurable average current limit, which support flexible designs for different applications.

The MP2980 also equips configurable overcurrent protection (OCP), overvoltage protection (OVP), and V_IN undervoltage lockout (UVLO) hysteresis. The device is housed in a QFN-32 (4mm x 4mm) package.

Features

6V to 36V start-up Input Voltage (V_IN) range
5V to 36V operating V_IN range
Flexible digital interface control:
- 0.5V to 28V Output Voltage (V_OUT) range
- 0.3V to 2.047V Reference Voltage (V_REF) range with 1mV step
Selectable V_OUT slew rate
Configurable constant current limit
Output Current (I_OUT) Monitor Function (I_MON)
Configurable Soft-Start Time (t_SS)
Switching Frequency Spread Spectrum (FSS) for EMI optimization

Integrated V_OUT discharge function
Selectable 200kHz, 300kHz, 400kHz, and 600kHz Switching Frequency (f_SW)
Forced Continuous Conduction Mode (FCCM)
Configurable V_IN Under-Voltage Lockout (UVLO) Hysteresis
Minimum V_IN regulation
Over-Current Protection (OCP), Short Circuit Protection (SCP), and Over-Voltage Protection (OVP)
Interrupt indicator for OCP, OVP, and V_OUT Power Not Good (PNG)
Available in a QFN-32 (4mm x 4mm) package
